Single Pole Trip Ac Mcb

ICHYTI has been committed to Quality single pole trip ac mcb designing, R&D, manufacturing and marketing for decades. QUALITY is our CULTURE. With qualified raw materials and components, all products are manufactured to defined specifications, applying ISO9001 quality control system and in compliance with relevant international approvals, such as RoHS, CE, TUV.

Send Inquiry PDF DownLoad

Product Description

China ICHYTI Cheap single pole trip ac mcb is suitable for single pole 240V and two, three, and four pole 415V AC circuits, used to protect circuits that may experience overload and short circuits. It is widely used in lighting and motor distribution systems, and is suitable for normal situations where electrical equipment and lighting circuits are not frequently switched. The high breaking capacity of circuit breakers ensures their reliability and safety when subjected to high loads.

ICHYTI single pole trip ac mcb Parameter (Specification)

Product Model	NBT2-125H
Pole	1P	2P	3P	4P
Rated Current (A)	80, 100, 125
Rated Voltage (V)	230	230/400	400	400
Breaking Capacity(kA)	10
Colour	White
Characteristic Curve	D
Working Temperature	-5℃〜+40°C
Enclosed Class	IP20
Standard	IEC60947-2
Frequency	50/60HZ
Electrical Life	Not less than 6000 times
Mechanical Life	Not less than 20000 times

ICHYTI single pole trip ac mcb Feature

◉ The speed of the manual operation handle has a positive impact on the service life of the product.

◉ The shell and some functional components are made of imported plastic with high flame retardancy, high temperature resistance, and impact resistance.

◉ The maximum connection capacity is 16 square millimetre, and the wiring torque is 25 Nm, which is suitable for various installation equipment.

◉ The operation of the handle feels very comfortable.
